nanoFIBER OM4 Multimode Cassettes
Model Number: NF-ISOM4A-12AQ with Aqua LC Shuttered Adapters
|
ELEMENT |
DESCRIPTION |
|
FIBER TYPE |
MM 50/125 OM4 |
|
FIBER COUNT |
12f |
|
POLARITY MAPPING |
Method A |
|
ADAPTERS |
Rear MTP Black Body | Front: 3 X LC (quad) with internal shutter; Body Color: Black; Erica Violet (OM3/OM4) Blue (SM/UPC), Green (SmAPC) |
|
INTERNAL ASSEMBLY CONNECTORS |
MPO MM: Low Loss Premium Male (12-fiber ferrule); LC MM/ Low Loss Premium |
|
CASSETTE MATERIAL |
ABS |
|
CASSETTE COLOR |
Black |
|
STORAGE TEMPERATURE |
-40 C – +175 C |
|
OPERATING TEMPERATURE |
-40 C – + 175 C |
|
CASSETTE DIMENSIONS |
4.5” L x 3.75” W x .5” H |
|
PACKAGE DIMENSIONS |
10” L x 6” W x .5” H |
|
CASSETTE WEIGHT |
2.8 oz (.0795 kg) |
|
CASSETTE WEIGHT (PACKAGED) |
2.96 oz (.084kg) |
|
MATERIALS COMPLIANT TO |
RoHS |
|
CONNECTOR MATING |
INSERTION LOSS AVG |
INSERTION LOSS MAX |
RETURN LOSS |
|
MPO Low Loss Premium (MM) |
.074dB |
.20dB |
N/A |
|
LC Low Loss Premium (MM) |
.076dB |
.15dB |
N/A |
|
FIBER TYPE |
OM4 |
|
Attenuation Coefficient (dB/km) |
<= 3.5 Max (850mm) <= 1.5 Max (1300nm) <= 2.7 Typ (850nm) <= 0.9 typ (1300 nm) |
|
Minimum Bandwith: Overfilled Launch (Mhz- km) |
>= 3500 (850nm) >= 500 (1300nm) |
|
Minimum Bandwith: Lastser Effective Medal Bandwith (MhZ-km) |
>= 4700 (850nm) |
Downloadable PDF File: NF-ISOM4A-12FAQ NANOFIBER OM4 CASSETTE SPEC SHEET
